WFQ700-1300 Series Horizontal Computer Slitting Machine

1)Functions and Characteristics:
This machine is suitable for slitting and rewinding such various roll materials as BOPP,PET,CPP,PVC, aluminum foil and paper.,etc. and can cut edge,separate and cut material according to different requirements during production.
2)  Performance and Characteristics:
1. Main Motor: Vector motor with inverter controller.
2. Independent master control panel, more flexible and easier operation.
3. Automatic EPC for unwinding, photocell is suitable for tracking the edge
 and the printed line of material.
4. Equipped with air shaft for unwinding material loading, magnetic powder
 brake for unwinding tension control.
5. Air shaft for rewinding, Magnetic powder clutch for rewinding
tension control
6. Equipped with air trim discharge conveying system.
7. Automatic meter counting device.
8. Pressure roller for rewinding to make rewinding roll more uniform.



Main Technical Variables:

 Type WFQ-700 WFQ-1100 WFQ-1300
Max.Width of Mother 600mm 1000MM 1200mm
Max.diameter of Mother Roll Φ600mm Φ600mm Φ600mm
Width of Final Roll 30-600mm 30-600mm 30-600mm
Slitting and Rewinding Speed 5-180m/min 5-180m/min 5-180m/min
Motor Power 2.7kw 3.5kw 3.5kw
Weight of Machine 1800kg 2000kg 2200kg
Overall Dimension 2100*1800*1200mm 2100*2000*1200mm 2200*2100*1200mm
