Dua Warna Mesin Pembuat Sedotan Polypropylene Plastik
Tanyakan Tongkat
OEM：
Available
Sample：
Available
Port：
Ningbo
Payment：
PayPal,VISA,MasterCard,Western Union,L/C,T/T
Place of Origin：
China
Shipping：
Sea freight · Land freight · Air freight
Supply Ability：
300 unit per Year
Perincian Produk
Dua Warna Mesin Pembuat Sedotan Polypropylene Plastik
TECHNICAL FEATURE
1. The extrusion die can be special designed and easy exchanged to produce pipe and shaping stuff,
2.Water bath in stainless steel can be adjusted in three planes ,
3.The haul-off unit can be belt.
4.Fitted with single rotary cutter.
5.Conveyor device(you may select if you want)
SPECIFICATIONS
|
Model
|
KD-12 Dua warna
|
|
|
Parameter of main screw
|
φ50mm(diameter) ×2
|
|
|
Parameter of sub- screw
|
0
|
|
|
Capability
|
30~50Kg/h
|
|
|
Power
supply
|
Main motor
|
11kW×2 380v 50Hz (VFD)
|
|
Haul-off motor
|
0.37kW×2(VFD)
|
|
|
Cutting motor
|
0.75kW×1(VFD)
|
|
|
Temperature controller
|
11zone
|
|
|
Length of cooling container
|
3400mm/6400mm
|
|
|
Specifications
|
diameter:φ3~12mm thickness:0.05~1mm
|
|
|
Machine weight
|
2000KG
|
|
|
Dimension
|
1600mm(W)×9000mm(L)
|
|
|
Other specifications are customizable
|
||
